ELEX SMD LED LAMP TOWER LIGHT 48SMD LED

Technical Specifications

1.Aux. Supply :140- 270 VAC (standard) or 12/24/48V DC

2.Top Cover :Poly-carbonate RED UV/Impact Resistant

                         (Unbreakable from the height of 1 meter)

3.Housing :Cast aluminum base Bright Yellow(LM 6)

4.Protection :Weather proof IP 65*

5.LED Wattage :30W@250V AC Max.

6.Light Source :LED Lamp 48 smd LED

7.Intensity :10000 - 14000 mcd each LED

8.Angle of LED :120° for greater illumination

9.LED :100,000 hours

10.Out put LED Power :15-21VDC/600MA/±30MA

11. Efficiency :>85%/

12.Power Factor :>0.95 AT RATED MAX./2KV

13.Protection :SHORT CIRCUIT PROTECTION

14.Isolation :WITHSTAND VOLTAGE 4KV

15.Cut Off : LED cut off below 50 V AC

16.Re ON : At 140 V AC

17.Size :Dia-170 Ht-240 Dome Ht-200mm

18Operation : Automatic ON at night & OFF at day hour

with built in electronic solid state circuit

19.LUX Level :50 LUX @ 1 meter

                          2000 LUX @ 100cm
